How to Build Millions of Tiny Microscopes All at Once

A new optical device made of silicon “nanopillars” could lead to advanced microscopes, displays, sensors, and cameras that can be mass-produced using the same techniques used to manufacture computer microchips.
How to Build Millions of Tiny Microscopes All at Once
(ramzihachicho/iStock)
9/1/2015
Updated:
8/31/2015

A new optical device made of silicon “nanopillars” could lead to advanced microscopes, displays, sensors, and cameras that can be mass-produced using the same techniques used to manufacture computer microchips.

“Currently, optical systems are made one component at a time, and the components are often manually assembled,” says Andrei Faraon, an assistant professor of applied physics and materials science at Caltech. “But this new technology is very similar to the one used to print semiconductor chips onto silicon wafers, so you could conceivably manufacture millions of systems such as microscopes or cameras at a time.”

Seen under a scanning electron microscope, the new metasurfaces that the team created resemble a cut forest where only the stumps remain. Each silicon stump, or pillar, has an elliptical cross section, and by carefully varying the diameters of each pillar and rotating them around their axes, the scientists were able to simultaneously manipulate the phase and polarization of passing light.

Light is an electromagnetic field, and the field of single-color, or monochromatic, light oscillates at all points in space with the same frequency but varying relative delays, or phases. Manipulating this relative delay, or phase, influences the degree to which a light ray bends, which in turn influences whether an image is in or out of focus.

Polarization refers to the trajectory of the oscillations of the electromagnetic field at each point in space. Manipulating the polarization of light is essential for the operation of advanced microscopes, cameras, and displays; the control of polarization also enables simple gadgets such as 3-D glasses and polarized sunglasses.

“Using our metasurfaces, we have complete control of the polarization and phase of light,” says Amir Arbabi, a senior researcher at Caltech and first author of the study published in Nature Nanotechnology. “We can take any incoming light and shape its phase and polarization profiles arbitrarily and with very high efficiency.”

Much Thinner Than A Human Hair

While the same goal can be achieved using an arrangement of multiple conventional optical components such as glass lenses, prisms, spatial light modulators, polarizers, and wave plates, these many components lead to much bulkier systems.

“If you think of a modern microscope, it has multiple components that have to be carefully assembled inside,” Faraon says. “But with our platform, we can actually make each of these optical components and stack them atop one another very easily using an automated process. Each component is just a millionth of a meter thick, or less than a hundredth of the thickness of a human hair.”

In addition to being compact, a metasurface device could manipulate light in novel ways that are very hard and sometimes impossible to do using current setups.

For example, the Caltech team showed that one of their metasurfaces can project one image when illuminated by a horizontally polarized beam of light, and a different image when illuminated by a vertically polarized beam. “The two images will appear overlapped under illumination with light polarized at 45 degrees,” Faraon says.

Miniature Cameras And More

In another experiment, the team was able to use a metasurface to create a beam with radial polarization, that is, a beam whose polarization is pointing toward the beam axis. Such beams have doughnut-shaped intensity profiles and have applications in superresolution microscopy, laser cutting, and particle acceleration.

“You generally would need a large optical setup, consisting of multiple components, to create this effect using conventional instruments,” Arbabi says. “With our setup, we can compress all of the optical components into one device and generate these beams with higher efficiency and more purity.”

The team is currently working with industrial partners to create metasurfaces for use in commercial devices such as miniature cameras and spectrometers, but a limited number have already been produced for use in optical experiments by collaborating scientists in other disciplines.

In addition, the Faraon lab current is investigating ways to combine different metasurfaces to create functioning optical systems and to correct for color distortions and other optical aberrations.

“Like any optical system, you get distortions,” Faraon says. “That’s why expensive cameras have multiple lenses inside. Right now, we are experimenting with stacking different metasurfaces to correct for these aberrations and achieve novel functionalities.”

Source: CaltechRepublished from Futurity.org under Creative Commons License 4.0.
